GENESYS-APL7-A10-FS02
Brand: AAEON [An ASUS Co.]
Categories: IoT Gateway
GENESYS-APL7-A10-FS02 is a powerful industrial motherboard with Intel® Pentium® N4200 processor.
It offers up to 8GB RAM support and mSATA/SATA storage options.
It provides high connectivity with 2 x GbE ports, VGA output and RS-232/422/485 ports.
It offers safe and durable use with DC 12V supply voltage and operating temperature between 0°C and 50°C.
It provides a flexible and efficient solution for various industrial applications.
Features
| Product Code | GENESYS-APL7-A10-FS02 |
| Cooling | Heat Sink + Fan |
| Processor [CPU] | Intel® Pentium® N4200 4 Core 1.10 / 2.40 GHz | BM : 2150 |
| Processor [CPU] Family | Intel® Pentium® |
| RAM [System Memory] | [Max 8 GB] |
| SSD/HDD/mSATA/M.2 | mSATA x 1 |
| LAN/Ethernet | GbE x 2 |
| USB 3.2 | x1 |
| USB 2.0 | x2 |
| RS 232 Serial Port | x 1x 6 (PIN) |
| Video Output | VGA x 1 |
| Expansion Slot | Full Size Mini-PCIe x 1 | mSATA x 1 |
| Supply Voltage | DC 12V |
| Working temperature | 0°C ~ 50°C |
| External Dimensions (mm) | 178 x 134.1 x 50 |
| Body Material | Aluminum |
| Certificates | CE | FCC |
| Supported Operating Systems | Windows®10 | Windows®8 | Windows®7 | Linux Ubuntu 22.04 | Operating system license is not included. |
