SI-613-QT

Brand: IBASE
Categories: Book-Size Signage Player

Winner of the 2016 COMPUTEX d&i award, the SI-613 is a 3x4K UHD digital signage system designed for digital menu boards and multi-screen video wall applications. In addition to boasting three ultra-high-definition 3x4K resolutions, the product is built with separate-flow ventilation and supports the latest 6th and 7th generation Intel® Core processors. The SI-613 comes with hardware EDID (extended display identification data) simulation to prevent screen convergence issues and issues caused by cable disconnection, undefined EDID, or incorrect hardware or digital playback software settings. The use of a separate ventilation system keeps the circuit board free of dust and dirt. The system is also integrated with IBASE. The unique iSMART intelligent energy-saving technology and iDOC remote network monitoring technology, which users can operate directly from a web-based interface for energy savings, automatic power on/off scheduling, power auto-recovery, and low-temperature boot protection. Thanks to its slim chassis, the screen can be perfectly hidden behind small spaces, saving space.


Features


Product Code SI-613-QT
Processor [CPU] Intel® Core™ i7-7600U 2 Core 2.80 GHz | BM : 3720
Processor [CPU] Family Intel® Core™ i7 7th Gen
RAM [System Memory] [Max 32 GB]
SSD/HDD/mSATA/M.2 64 GB mSATA
LAN/Ethernet GbE x 2
USB 3.0 x2
USB 2.0 x2
RS 232 Serial Port x1
Video Output HDMI x 3
Expansion Slot M.2 B Key x 1 | Full Size Mini-PCIe x 1
Mounting Type wall mount
Supply Voltage DC 12V
Working temperature 0°C ~ 45°C
External Dimensions (mm) 215.6 x 215.6 x 40
Body Material Aluminum
Certificates CE | FCC
