RTC-1010RK-R0002
Brand: AAEON [An ASUS Co.]
Categories:
RTC-1010RK-R0002 provides powerful performance with its Rockchip RK3399 processor and 4GB RAM.
The 10.1" WXGA display provides clear visuals with 300 cd/m² brightness.
It offers advanced communication support with dual cameras (front and rear) and 4G LTE module.
Projective capacitive [P-CAP] touch screen provides user interaction with high sensitivity.
It offers flexible software support with Android 10.x and Android 11.x operating systems.
Features
| Product Code | RTC-1010RK-R0002 |
| Screen size | 10.1" TFT LCD |
| Resolution | 1280 x 800 |
| Screen Format | 16 | 10 |
| Brightness | 300 cd/m² |
| Contrast | 1000 | 1 |
| Touch Type | Projective Capacitive [P-CAP] |
| Cooling | Fanless |
| Processor [CPU] | RockChip™ RK3399 + Dual Core Cortex® A72 1.80 GHz + Cortex® A53 Quad Core 1.40 GHz |
| Processor [CPU] Family | RockChip™ |
| RAM [System Memory] | 4 GB Onboard |
| SSD/HDD/mSATA/M.2 | 64 GB eMMC |
| LAN/Ethernet | GbE x 1 |
| USB 3.2 | Type Cx 1 |
| USB 2.0 | x1 |
| RS 232/422/485 Serial Port | x1 |
| Video Output | Micro-HDMI x 1 |
| Audio Output | Line-out x 1 |
| Expansion Slot | Micro SD x 1 |
| Wireless | 802.11 |
| Bluetooth | V4.2 (EDR (+) BLE) |
| Front camera | 8MP |
| Rear Camera | 8 MP Flashlight |
| 4G - LTE | Optional |
| GPS | (+) |
| G Sensor | (+) |
| 2D/QR Code Reader | (+) |
| Light Sensor x 1 | (+) |
| E-Compass | (+) |
| Gyro-Sensor | (+) |
| Battery | 14.4V/2270mAh/32.7W |
| placement | Optional |
| Supply Voltage | DC 9-19V |
| Working temperature | -20°C ~ 60°C |
| External Dimensions (mm) | 272 x 190 x 21 |
| IP Protection Class | Front IP65 |
| Certificates | CE | FCC | MIL-STD-810H | TELEC |
| Supported Operating Systems | Android 10.x | Android 11.x |
