PICO-ADN4-B10-0001
Brand: AAEON [An ASUS Co.]
Categories:
PICO-ADN4-B10-0001 delivers powerful performance with Intel® N97 processor, ensuring high efficiency in industrial applications.
It increases data processing capacity with DDR4 RAM and large storage space.
Provides fast network connection with dual GbE Ethernet connection.
It offers easy integration with various displays with HDMI 1.4 and eDP 1.4b video outputs.
It can operate safely in the temperature range of -20°C to 70°C.
Features
| Product Code | PICO-ADN4-B10-0001 |
| Form Factor | PICO-ITX |
| Card Size (mm) | 100 x 72 |
| Processor [CPU] | Intel® N97 4 Core 3.60 / 3.60 GHz | BM : 5930 |
| Processor [CPU] Family | Intel® Processor N® |
| RAM [System Memory] | DDR4 |
| SSD/HDD/mSATA/M.2 | SATA3 x 1 |
| LAN/Ethernet | GbE x 1 | 2.5GbE x 1 |
| USB 3.2 | x2 |
| USB 2.0 | x4 |
| Digital I/O | GPIO |
| Video Output | HDMI 1.4 x 1 |
| LVDS | eDP1.4 x 1 |
| Expansion Slot | M.2 2230 E-key x 1|miniCard (Full) x 1 |
| SMBUS | x1 |
| TPM | TPM 2.0 |
| 4G - LTE | Optional |
| Supply Voltage | DC 12V |
| Working temperature | -20°C ~ 70°C |
| External Dimensions (mm) | 100 x 72 |
| Certificates | CE |
| Supported Operating Systems | Windows®10 | Linux Ubuntu 22.04 | Operating system sold separately from license. |
