| Product Code |
MPT-3000V |
| Cooling |
Fanless
|
| Processor [CPU] |
Intel® Atom® E3845 4 Core 1.91 GHz | BM : 1130
|
| Processor [CPU] Family |
Intel® Atom®
|
| RAM [System Memory] |
4 GB Standard 4 GB DDR3L
|
| SSD/HDD/mSATA/M.2 |
2.5" SATA 64 GB
|
| LAN/Ethernet |
GbE x 2
|
| USB 3.0 |
x1
|
| USB 2.0 |
x2
|
| RS 232 Serial Port |
x2
|
| RS 232/422/485 Serial Port |
x1
|
| Video Output |
VGA x 1 + DVI-D x 1
|
| Expansion Slot |
Full Size Mini-PCIe x 1 | Half Size Mini-PCIe x 2 | M.2 E Key x 1 | PCIe [x1] x 1 | PCIe [x1] x 1
|
| Mounting Type |
Custom Mount
|
| Supply Voltage |
DC 9-36V
|
| Working temperature |
-40°C ~ 70°C
|
| External Dimensions (mm) |
256 x 182 x 55
|
| Body Material |
Aluminum
|
| Certificates |
CE | FCC | E-Mark
|
| Supported Operating Systems |
Windows®10 | Windows®8 | Windows®7 | Linux Ubuntu 22.04 | Operating system license is not included.
|
