MPT-3000R
Brand: IBASE
Categories: Smart Transportation Products
Designed with a separate wireless power module and network communication capabilities, the MPT-3000R is a multi-purpose IoT rail system supporting dual WAN Slots, enabling versatile wireless communication. Unlike competing products with an all-in-one architecture, this innovative system can be adapted to meet varying power requirements. Built with a separate, replaceable self-protecting power module, the MPT-3000R is suitable for rail applications and utilizes SSD storage, has an operating temperature range of -40°C to 70°C, and features built-in adjustable three-axis G-sensor shock protection.
Based on the MBT-3001 motherboard, the MPT-3000R is powered by the 1.91GHz Intel® Atom™ Processor E3845 processor. It is housed in a black aluminum chassis and houses two DDR3L-1333 SO-DIMM dual-channel sockets with a total of 4GB of system memory.
Features
| Product Code | MPT-3000R |
| Cooling | Fanless |
| Processor [CPU] | Intel® Atom® E3845 4 Core 1.91 GHz | BM : 1130 |
| Processor [CPU] Family | Intel® Atom® |
| RAM [System Memory] | 4 GB Standard 4 GB DDR3L |
| SSD/HDD/mSATA/M.2 | 2.5" SATA 64 GB |
| LAN/Ethernet | GbE x 2 [M12] |
| USB 3.0 | x1 |
| USB 2.0 | x 2 [M12] |
| RS 232 Serial Port | x2 |
| RS 232/422/485 Serial Port | x1 |
| Video Output | VGA x 1 + DVI-D x 1 |
| Expansion Slot | Full Size Mini-PCIe x 1 | Half Size Mini-PCIe x 2 | M.2 E Key x 1 | PCIe [x1] x 1 | PCIe [x1] x 1 |
| Mounting Type | Custom Mount |
| Supply Voltage | DC 9-36V |
| Working temperature | -40°C ~ 70°C |
| External Dimensions (mm) | 256 x 182 x 68 |
| Body Material | Aluminum |
| Certificates | CE | FCC | EN50155 |
| Supported Operating Systems | Windows®10 | Windows®8 | Windows®7 | Linux Ubuntu 22.04 | Operating system license is not included. |
