| Product Code |
MI985 |
| Form Factor |
Full Size CPU Card
|
| Card Size (mm) |
338 x 126
|
| Processor [CPU] |
Intel® Xeon® |Core™ i7 | i5 | i3 | Pentium® | Celeron®
|
| Processor [CPU] Family |
Configurable Intel® Xeon® |Core™ i7 | i5 | i3 | Pentium® | Celeron®
|
| RAM [System Memory] |
[Max 16 GB]
|
| SSD/HDD/mSATA/M.2 |
SATA2 x 1 | SATA3 x 3 | RAID
|
| LAN/Ethernet |
GbE x 2
|
| USB 2.0 |
x3
|
| RS 232 Serial Port |
x3
|
| RS 232/422/485 Serial Port |
x1
|
| Video Output |
DVI-D x 1 + LVDS x 1 + CRT x 1
|
| Digital I/O |
DIx 4 / DOx 4
|
| Expansion Slot |
Mini-PCIe x 1
|
| Supply Voltage |
DC 12V | DC 5V | DC 3.3V
|
| Certificates |
CE
|
