| Product Code |
MI982 |
| Form Factor |
Full Size CPU Card
|
| Card Size (mm) |
338 x 126
|
| Processor [CPU] |
Intel® Xeon® |Core™ i7 | i5 | i3 | Pentium® | Celeron®
|
| Processor [CPU] Family |
Configurable Intel® Xeon® |Core™ i7 | i5 | i3 | Pentium® | Celeron®
|
| RAM [System Memory] |
[Max 16 GB]
|
| SSD/HDD/mSATA/M.2 |
mSATA x 1 | SATA3x4 | SATA x 2
|
| LAN/Ethernet |
GbE x 2
|
| USB 3.0 |
x4
|
| USB 2.0 |
x4
|
| RS 232 Serial Port |
x3
|
| RS 232/422/485 Serial Port |
x1
|
| Video Output |
LVDS x 1
|
| Digital I/O |
DIx 4 / DOx 4
|
| Expansion Slot |
Mini-PCIe x 1 | PCIe [x1] x 1 | PCIe [x1] x 1
|
| Supply Voltage |
ATX
|
| Certificates |
CE
|
