| Product Code |
MI979MF-421D |
| Form Factor |
Mini-ITX
|
| Card Size (mm) |
170 x 170
|
| Processor [CPU] |
AMD® RX-421BD 4 Core 2.10 / 3.40 GHz | BM : 3300
|
| Processor [CPU] Family |
AMD®
|
| RAM [System Memory] |
[Max 16 GB]
|
| SSD/HDD/mSATA/M.2 |
M.2 M Key x 1 | SATA3 x 2
|
| LAN/Ethernet |
GbE x 2
|
| USB 3.0 |
x2
|
| USB 2.0 |
x4
|
| RS 232 Serial Port |
x5
|
| RS 232/422/485 Serial Port |
x1
|
| Video Output |
HDMI x 1 + DP x 1
|
| Digital I/O |
DIx 4 / DOx 4
|
| Expansion Slot |
Mini-PCIe [x1] x 1 | PCIe [x1] x 1 | PCIe [x1] x 1
|
| Supply Voltage |
DC 5 | DC 3.3 V
|
| Certificates |
CE
|
