INOSP-191-RE
Brand: IBASE
Categories:
INOSP-191-RE is a 19" stainless steel panel computer that adopts dual Core 1.86GHz Intel® Atom™ Processor D2550 and Intel® NM10 chipset, providing high processing performance and low power consumption.
The fanless INOSP-191-RE operates quietly and reliably in harsh environments, comes with up to 4GB DDR3 1033/1066MHz system memory and two SODIMM slots to accommodate one 2.5-inch SATA HDD and an external CFast slot for data storage. M2M
The INOSP-191-RE has been proven to work well in temperature environments from 0 to 50 degrees Celsius and supports a wide 12V~36V DC power input range with an Optional 24V DC IP56 stainless steel power adapter, making it ideal for cooking.
Features
| Product Code | INOSP-191-RE |
| Screen size | 19" TFT LCD |
| Resolution | 1280 x 1024 |
| Screen Format | 5 | 4 |
| Brightness | 350 cd/m² |
| Contrast | 1000 | 1 |
| Viewing Angle | 170°(H) / 170°(V) |
| Touch Type | Resistive |
| Backlight Life (Min. Hours) | 50000 |
| Cooling | Fanless |
| Processor [CPU] | Intel® Atom™ D2550 2 Core 1.86 GHz BM : 730 |
| Processor [CPU] Family | Intel® Atom® |
| RAM [System Memory] | 4 GB Standard DDR4L |
| SSD/HDD/mSATA/M.2 | 2.5" SATA x 1 | [Upgradeable] |
| LAN/Ethernet | GbE x 2 |
| USB 2.0 | USB 2.0 (USB Host. Type A)x 2 |
| RS 232 Serial Port | x1 |
| RS 232/422/485 Serial Port | x1 |
| Video Output | x 0 |
| Audio Output | Mic-in x 1 + Line-out x 1 |
| Mounting Type | VESA 75 | Panel Mount | Stand | Mounting Unit Not Included. |
| Supply Voltage | DC 12-36V |
| Working temperature | 0°C ~ 50°C |
| External Dimensions (mm) | 470 x 388 x 60 |
| Body Material | Aluminum |
| IP Protection Class | Front IP65 |
| Certificates | CE | FCC |
| Supported Operating Systems | Windows®10 | Windows®8 | Linux | Operating system license sold separately. |
