GENE-WHU6-A11-0003
Brand: AAEON [An ASUS Co.]
Categories:
GENE-WHU6-A11-0003 provides high performance with 8th Generation Intel® Core™ processors.
It offers powerful memory management with 64 GB DDR4 RAM support.
It provides extensive connectivity with four USB 3.2 Gen2, two Gigabit Ethernet and RS-232/422/485 ports.
It can be used in harsh conditions with its 9-36V wide voltage input and ability to operate between -40°C and 85°C.
It provides general functionality, providing big functionality in small machines.
Features
| Product Code | GENE-WHU6-A11-0003 |
| Form Factor | 3.5" Subcompact Board |
| Card Size (mm) | 101.6 x 146 |
| Cooling | Optional: Heat Sink |
| Processor [CPU] | Intel® Core™ i5-8265U 4 Core 1.60 GHz | BM : 6050 |
| Processor [CPU] Family | Intel® Core™ i5 8th Gen |
| RAM [System Memory] | [Max 16 GB] |
| SSD/HDD/mSATA/M.2 | mSATA x 1 | SATA3 x 1 |
| LAN/Ethernet | GbE x 2 |
| USB 3.2 | x4 |
| RS 232 Serial Port | x1 |
| RS 232/422/485 Serial Port | x2 |
| Video Output | HDMI x 1 + VGA x 1 + LVDS x 1 |
| Digital I/O | DIOx 8 |
| LVDS | 18/24 bit 2CH x 1 |
| Expansion Slot | M.2 E Key x 1 |
| 4G - LTE | Nano SIM (Optional) |
| Supply Voltage | DC 9-36V |
| Working temperature | 0°C ~ 60°C |
| Certificates | CE |
| Supported Operating Systems | Windows®10 | Linux | Operating system sold separately from license. |
