EPIC-ADS7-PUC-A11-0003
Brand: AAEON [An ASUS Co.]
Categories:
EPIC-ADS7-PUC-A11-0003 is a high-performance industrial EPIC motherboard with 12th Generation Intel® Core™ S series processors.
It has a compact design with dimensions of 260 mm x 160 mm.
It offers 2.5GbE LAN, 2 x DP 1.4a, HDMI 2.0b, USB 3.2 Gen 2x2, USB 3.2 Gen 2 and USB 2.0 connectivity options.
It provides expandable storage support with M.2 expansion slots and dual SATA ports.
It provides reliable performance with CE/FCC Class A compliance and Windows 10/Linux Ubuntu support.
Features
| Product Code | EPIC-ADS7-PUC-A11-0003 |
| Form Factor | EPIC System |
| Cooling | Fanless |
| Processor [CPU] | Intel® Xeon® |Core™ i7 | i5 | i3 | Pentium® | Celeron® |
| Processor [CPU] Family | Configurable Intel® Xeon® |Core™ i7 | i5 | i3 | Pentium® | Celeron® |
| RAM [System Memory] | DDR5 SODIMM x 2 |
| SSD/HDD/mSATA/M.2 | SATA 6.0 GBps x 2 |
| LAN/Ethernet | GbE x 3 |
| USB 3.2 | x1 |
| USB 2.0 | x2 |
| Serial Port | COM1 (RS232/422/485, support RI only)COM2 (RS232/422/485, support 5V/12V,RI) |
| RS 232/422/485 Serial Port | COM1 (RS232/422/485, support RI only)COM2 (RS232/422/485, support 5V/12V,RI) |
| Video Output | HDMI x 1 |
| Expansion Slot | M.2 3052 B-key x 1(PCIe[x2]+ USB3), M.2 2280 M-key x 1 M.2 2230 E-key x 1 |
| Supply voltage | DC 12V |
| Working temperature | 0°C ~ 50°C |
| External Dimensions (mm) | 260 x 160 x 55 |
| Certificates | CE/FCC Class A |
| Supported Operating Systems | Windows®10 | Linux Ubuntu 20.04 | Operating system sold separately from license. |
