BOXER-8223AI-JP46E-A1-1010
Brand: AAEON [An ASUS Co.]
Categories: Ultra Slim Box PC
BOXER-8223AI-JP46E-A1-1010, AI@Edge Compact Fanless Embedded BOX PC with NVIDIA® Jetson™ Nano™.
It features a Quad Core ARM® Cortex®-A57 MPCore + 128 CUDA cores delivering 472 GFLOPs of processing power.
4GB RAM, 16GB eMMC storage + expandable data capacity via MicroSD x 1.
Extensive connectivity options with PoE x 2, 4 x USB 3.2, 1 x RS-232/485, HDMI x 1 video output.
DC 10-24V supply, can operate in the temperature range of -10°C ~ 70°C, supports Linux (NVIDIA Jetpack™ 4.6).
Features
| Product Code | BOXER-8223AI-JP46E-A1-1010 |
| AI Accelerator| GPU | NVIDIA® Jetson™ Nano™ |
| Cooling | Fanless |
| Processor [CPU] | Quad Core ARM® Cortex® A57 MPCore |
| Processor [CPU] Family | ARM® |
| RAM [System Memory] | 4 GB Onboard |
| SSD/HDD/mSATA/M.2 | 16 GB eMMC | MicroSD x 1 | 2.5" SATA x 1 |
| LAN/Ethernet | PoE x 2 |
| USB 3.2 | x4 |
| RS 232/485 Serial Port | x1 |
| Video Output | HDMI x 1 |
| Mounting Type | wall mount |
| Supply Voltage | DC 10-24 V |
| Working temperature | -10°C ~ 70°C |
| External Dimensions (mm) | 180 x 136 x 61.1 |
| Body Material | Aluminum |
| Certificates | CE | FCC |
| Supported Operating Systems | Linux (NVIDIA Jetpack™ 4.6) |
