BOXER-6842M-A5-1011
Brand: AAEON [An ASUS Co.]
Categories: Expandable Box PC
BOXER-6842M-A5-1011 is an expandable Industrial Box PC designed for high-performance machine vision and automation applications.
It delivers powerful computing performance with Intel® Xeon® | Core™ 8th Gen i9 | i7 | i5 | i3 | Intel® Pentium® processors.
[Max 128GB] RAM support provides expansion with mSATA x 1 | SD x 1 | 2.5" SATA x 2 | RAID | M.2 NVMe x 1 storage options.
It offers extensive connectivity options with 5 x GbE LAN ports, 4 x USB 3.2, 4 x RS-232/422/485 serial ports and HDMI x 2 + DVI-I video output.
DC 12-24V wide voltage range, can work in the temperature range of 0°C ~ 40°C, and is compatible with Windows 10, Windows 8, Windows 7, Linux Ubuntu 22.04 operating systems.
Features
| Product Code | BOXER-6842M-A5-1011 |
| Cooling | Fanless |
| Processor [CPU] | Intel® Xeon® |Core™ i7 | i5 | i3 | Pentium® | Celeron® |
| Processor [CPU] Family | Configurable Intel® Xeon® |Core™ i7 | i5 | i3 | Pentium® | Celeron® |
| RAM [System Memory] | [Max 128 GB] |
| SSD/HDD/mSATA/M.2 | mSATA x 1 | SD x 1 | 2.5" SATA x 2 | RAID | M.2 NVMe x 1 |
| LAN/Ethernet | GbE x 5 |
| USB 3.2 | x4 |
| RS 232/422/485 Serial Port | x4 |
| Video Output | HDMI x 2 + DVI-I x 1 |
| Audio Output | Mic-in x 1 + Line-out x 1 |
| Expansion Slot | Full Size Mini-PCIe x 1 | Half Size Mini-PCIe x 1 | M.2 M Key x 1 | PCIe [x4] x 1 | PCIe [x8] x 1 |
| Mounting Type | wall mount |
| Supply Voltage | DC 12-24V |
| Working temperature | 0°C ~ 40°C |
| External Dimensions (mm) | 156.7 x 226.5 x 325 |
| Body Material | Aluminum |
| Certificates | CE | FCC |
| Supported Operating Systems | Windows®10 | Windows®8 | Windows®7 | Linux Ubuntu 22.04 | Operating system license is not included. |
